Equipment advantages:
1. Siemens control system can achieve high-speed communication and data transmission, with high reliability and stability, and is easy to remotely monitor and control.
2. Manual winding and automatic winding are optional.
3. Parallel rollers and transfer coating methods are optional.
4. Pioneering the design of cooling box structure to prevent condensation.
5. Floating roller+PLC+low friction cylinder+electric proportional valve closed-loop adjustment of tension, tension control accuracy can reach 1N.
Equipment parameters:
Item | Parameter |
Coating Mode | Teasing Roller Transfer Coating / Parallel Roller Coating |
Glue Application Amount | 10-150g/㎡ |
Coating Width | Max:1005mm |
Coating Accuracy | Weight 10g/m2±1g,Weight 50g/m2±1.5g |
Coating Speed | Max:50m/min(According to Length) |
Wrinkle Length of Roll Bottom | ±1°C |
Speed Accuracy | 0.3% |
*The above parameters are subject to the actual product
